NAiS FP Series User Manual

FPΣ
Specifications
13 - 30
(A: Available, N/A: Not available)
Address Name Description Reading Writing
DT90025 Maskconditionmonitoring
register for interrupts
(INT 0 to 7)
The mask conditions of interrupts using ICTL
instruction can be stored here. Monitor using
binary display.
0: interrupt disabled (masked)
1: interrupt enabled (unmasked)
15 11 7 3 0 (Bit No.)
23 19 16 (INT No.)
A N/A
DT90026 Not used N/A N/A
DT90027 Periodical interrupt
interval (INT 24)
The value set by ICTL instruction is stored.
- K0: periodical interrupt is not used
- K1 to K3000: 0.5ms to 1.5s or 10ms to 30s
A N/A
DT90028 Not used N/A N/A
DT90029 Not used
DT90030 Message 0 The contents of the specified message are stored
in
these
special
data
registers
when
F149
(MSG)
A N/A
DT90031 Message 1
in these special data registers when F149 (MSG)
instruction is executed.
DT90032 Message 2
instruction
is
executed
.
DT90033 Message 3
DT90034 Message 4
DT90035 Message 5
DT90036 Not used N/A N/A
DT90037 Operation auxiliary
register for search
instruction “F96 (SRC)”
The number of data that match the searched data
is stored here when F96 (SRC) instruction is
executed.
A N/A
DT90038 Operation auxiliary
register for search
instruction “F96 (SRC)”
The position of the first matching data is stored
here when an F96 (SRC) instruction is executed.
A N/A
DT90039 Not used N/A N/A
DT90040 Potentiometer (volume)
input V0
The potentiometer value (K0 to K1000) is stored
here. This value can be used in analog timers and
other applicationsby usingthe programto readthis
A N/A
DT90041 Potentiometer (volume)
input V1
other
applications
by
using
the
program
to
read
this
value to a data register.
V0→DT90040
V1→DT90041
DT90042 Used by the system. N/A N/A
DT90043 Used by the system. N/A N/A
