5
KEYPAD CONTROLS & INDICATORS
1. LCD Window – Displays system status
messages, zone descriptions, etc.
2. Bypass Icon – Appears as a reminder
that zones have been bypassed (by
pressing the BYPASS button). If it is
necessary to bypass any inoperative
zones, it is important to have the zones
repaired as soon as possible.
3. Fire Icon – Steady indicates a fire
alarm condition. Flashing indicates fire
alarm sounding.
4. Fire TBL Icon – Indicates a problem
on a fire zone is detected.
5. System TBL Icon – Indicates a trouble
condition exists on the system. Press
RESET to silence sounder and display
the trouble.
6. ARMED Light – Lights (red) to indicate
that the system is armed. If an alarm has
occurred, the ARMED LED will be
flashing.
7. STATUS Light – Lights (green) to
indicate that the system is ready for
arming. Turns off when any zone is
faulted other than the keypad PIR (the
zone displays in the LCD Window). If a
zone has been bypassed, the STATUS
light will blink when armed.
8. MENU Button – Selects available
system functions as displayed in the
LCD Window. The selected function is
executed by pressing the ENTER
button.
9. BYPASS Button – (1) Deactivates
selected zones from the system. (2)
Unbypasses a bypassed zone.
10. RESET Button – (1) Resets various
system troubles, displays, etc. (see text)
(2) Resets residential smoke detectors.
11. Alarm Siren – Will sound a LOUD
steady sweep tone when intrusion is
detected or a distinct pulsating tone for
a fire alarm condition. Also chirps to
indicate armed Away.
12. Emergency Buttons – Used with the
"star" button to signal an emergency, as
follows:
• Press the 7 and the G
buttons for Fire Emergency.
• Press the 8 and the G
buttons for Auxiliary Emergency.
• Press the 9 and the G
buttons for Police Emergency.
13. Voice Prompt & Mini Sounder
Speaker – Provides for audible voice
prompts.
14. Integral PIR – Used to detect intruders
when armed Away and your presence
near the keypad when disarmed. Do
not block.
15. AREA Button – Selects other areas and
is used with emergency buttons.
16. AWAY Button – (1) Arms all zones in
the system, with display indicating the
exit time remaining. (2) Scrolls LCD
Window display backward (PRIOR). (3)
Answers "NO" to questions in the LCD
Window display.
17. STAY Button – (1) Bypasses all Interior
Zones simultaneously ("Stay Mode") to
allow free movement within the
premises. Hold down the STAY button
when the system is armed in "Stay
Mode" to cancel entry delay on Exit/
Entry Zones, causing an instant alarm
upon violation. (2) Scrolls the LCD
Window display forward (NEXT). (3)
Answers "YES" to questions in the LCD
Window display.
18. ENTER Button – Entry key. Causes the
entered code or selected function to be
executed.
19. Numerical Keys (1-9, 0) – Used to
enter codes, zone numbers, etc.
