appliance components
1.0 getting to know your appliance
BurnerPilot
Glass guard
assembly
(LVX only)
Safety barrier
(LV only)
Door trim
Firebox
glass door
Glass guard
mounting
brackets
(LVX only)
Some features and components illustrated may vary depending on your model.
Heat rail
(LVX only)
Control cover
Valve / rating
plate / lighting
instructions
Single-sided model illustrated.
Battery holder
(including switch)
This owner’s manual is written for a complete series of linear fireplaces that have a range of different features and
specifications. Before reading this manual, be sure you know which model of fireplace that you have. This informa-
tion will have been filled out by the installer on the proceeding page and on the rating plate that is permanently
attached to the fireplace (see “appliance overview” section).
This manual is for the:
• Vector Series (model number prefix “LV”)
• Luxuria Series (model number prefix “LVX”)
If required, more detailed technical information is included in the fireplace installation manual.
The information throughout this manual is believed to be correct at the time of printing. Wolf Steel Ltd. reserves
the right to change or modify any information within this manual at any time without notice. Changes, other than
editorial are denoted by a vertical line in the margin.
Visit the Napoleon website for the most current version of your appliance’s manual.
