replacement parts
14.1 overview
Items may not appear exactly as illustrated
REF.
#
Description Part Number Stocked
TLV50 TLV62 TLV74
1
Safety Screen (Premium)
W565-0351-SER W565-0352-SER W565-0353-SER
2
Safety Barrier
W010-6179-SER W010-6180-SER W010-6181-SER
Yes
3
Fixed Door Assembly
W010-6163-SER W010-6168-SER W010-6176-SER
Yes
4
Door Trim
W715-1144-SER W715-1124-SER W715-1123-SER
5
Door Latch Assembly
W010-3554
6
High Limit Switch*
W660-0204
7
Napoleon Logo
W385-2010 Yes
8
Porcelain End Panel
W475-7883-BK2GL
9
Porcelain Panel (Rear)
W475-7886-BK2GL-SER W475-7887-BK2GL-SER W475-7888-BK2GL-SER
10**
Finishing Trim, Top/Bottom
W715-1307-BK1FT W715-1308-BK1FT W715-1309-BK1FT
11
Finishing Trim, Sides
W715-1306-BK1FT
* When your appliance is equipped with the optional Dynamic Heat Control System™.
** Parts not illustrated.
4
SAFETY SCREEN
1
2
3
8
9
5
6
7
11
