Pins with Dedicated Functions
Table 15. RMC Connector Pins with Dedicated Functions
Pin
Group
Pin Name
Direction
(from
Host
System)
I/O Standard Description
Power
GND
O
—
Digital ground from the RMC
connector host system.
3.3 V_AUX
O
—
3.3 V_AUX from the RMC
connector host system. The
rail is always on when the
main host system is connected
to power.
5 V
O
—
5 V from the RMC connector
host system.
FPGA_VIO
O
—
I/O voltage for the FPGA
3.3V
pins.
VIN_FILTERED
I
—
9 V to 30 V input to power the
device through the RMC
connector rather than through
the front panel connector.
VBAT
I
—
This pin may be used to
connect a longer life battery to
the RTC on the host system.
The RTC will track absolute
time as long as either the main
system battery or RMC battery
through VBAT pin contains
sufficient charge.
30 | ni.com | NI sbRIO-9607 User Manual
