Table 15. RMC Connector Pins with Dedicated Functions (Continued)
Pin
Group
Pin Name
Direction
(from
Host
System)
I/O Standard Description
C Series
DIO
ID_SELECT#[x]
OSCLK_DIO0[x]
TRIG_DIO1[x]
DONE#_DIO2[x]
CVRT#_DIO3[x]
SPIFUNC_DIO4[x]
SPICS#_DIO5[x]
MISO_DIO6]x]
MOSI_DIO7[x]
SPI_CLK[x]
I/O LVTTL
3.3V
LVTTL
5V
tolerant input
Signal conditioned C Series
DIO.
Refer to the
NI sbRIO-9607/9627 RMC
Design Guide for more
information about how to use
these signals to connect up to
two board-level C Series
modules to your RMC.
SLEEP
5V C Series
O 5 V
Resets
RST#
O
LVTTL
3.3V
Reset that indicates that the
main power is not ideal, or
that the RMC connector host
system has been reset.
SYS_RST#
I
LVTTL
3.3V
System reset used to reset the
RMC connector host system.
Asserting this pin causes the
RST# pin to also assert.
NI sbRIO-9607 User Manual | © National Instruments | 31
