Page 9
S6CP - CHEST PRESS
SKU: S6CP Desc: ONE CHEST PRESS
Overall Weight Width Length Height
Seat Frame only -271 lbs.
Seat Frame and (255+5 Tower) -864 lbs.
Seat Frame and (255+ 1 Tower) -880 lbs.
Seat Frame and (385+5 Tower) -1086 lbs.
50.4 in (128 cm) 57 in (145 cm) 74.9 in (190 cm)
Features
• Converging, dependant movement arms allow increased range
of movement
• Four bar function generator matches the user’s strength curve
• Hydraulic, adjustable back pad provides optimum initial stretch
• Zero pulley design results in extreme smoothness
• Dual grip positions allow for a varied workout
Fig. 15
- S6CP02
Muscles Exercised:
• Pectoralis Major
• Pectoralis Minor
• Anterior Deltoid
• Triceps
Fig. 16
Setup:
Adjust the seat height so handles are aligned with mid-chest. Adjust the
back pad to obtain the desired initial stretch. Select desired resistance
by turning main weight selection knob and add on weight lever. Grip
the vertical or horizontal handles and position elbows slightly below
shoulders. Position body with chest up, shoulders and head back
against back pad.
Performing the Exercise:
Extend the handles out with controlled motion until arms are close to full
extension. Slowly return the handles to the start position.
Fig. 17
Fig. 18
