Section 3: Features
170 Product Description
● Digit Counting
With Digit Counting, SMDR can selectively keep track of toll calls. For example, if the digit
count is nine, SMDR won’t include toll calls within the home area code. Digit Counting per-
mits SMDR to include only the types of calls you want to monitor.
● Digit Masking
Digit Masking lets you “X” out portions of the number dialed on the SMDR report. A digit
mask of seven, for example, masks out all exchange codes (NNXs) and local addresses. Digit
Masking makes it easier to keep track of calling patterns, without having to interpret each
individual number. You can also use Digit Masking to block out access and security codes.
● Duration Monitoring
SMDR can include calls of any duration, or only those that last longer than the interval you
specify. If you want to keep track of all trunk activity, use a short duration. To keep track of
only signiÞcant usage, use a longer duration.
● Extension Exclusion
You can selectively exclude extensions from the SMDR report. This ensures privacy for high-
proÞle callers. For example, the company attorney negotiating a merger may not want his
calls to show up on an in-house report.
● PBX Call Reporting
If you system is behind a PBX, you can have SMDR monitor all trafÞc into the PBX or just
calls placed over PBX trunks. The SMDR record can include all PBX calls (including calls to
PBX extensions) or just calls that include the PBX trunk access code.
● Serial and USB SMDR Communication
The system is compatible with both serial and USB SMDR devices. This gives you many
SMDR output options. For example, you can output the SMDR report to a high speed printer
or send it to disk through a PC’s serial or USB port (requires the USB driver which can be
downloaded from the NEC Technical Support web site - ws1.necii.com).
● Trunk Exclusion
Use Trunk Exclusion to exclude certain trunks not subject to per-call charges (like WATS
lines) from the SMDR report. This makes call accounting easier, since you review only those
calls with variable costs.
● Usage Summaries
SMDR can automatically print daily, weekly and monthly call activity summaries. Each sum-
mary includes the total number of regular trunk calls and ISDN trunk calls, and the costs for
each type. The daily report prints every day at midnight. The weekly report prints every Sun-
day night at midnight. The monthly report prints at midnight on the last day of the month.
● Extension Name or Number
The SMDR report can include an extension’s name or extension number. Choose the method
that makes it easier for you to track call usage.
SMDR Enhanced for Caller ID
Depending on your software version, the SMDR output is enhanced to include up to 16 or 24 char-
acters of the Caller ID name information (depending on the view option selected in Program 35-02-
18). You can select to display the Caller ID number or name or the DID number. If you wish to dis-
play the Caller Name in the “DIALLED NO./CLI” and “ACCOUNT" area, select "2" in the
updated Program 35-02-15 and "1" in Program 35-02-17.
If the Caller ID name is not received, the area for Caller ID Name is left blank.
