Section 2: Components
10 Product Description
● IP Adapter (P/N 0890060)
Provides the ability to communicate through a LAN which is connected to a VOIPU or 8SHUBU
PCB. The VOIPU or 8SHUBU PCB is required in order to communicate with non-VoIP Aspire
phones, as well as to place or receive outside calls. This adapter cannot be used on a Super Display
telephone.
This adapter requires an AC Adapter (AC-2R), P/N 780135.
● IPhone Power Failure Adapter (PSA) (P/N 0890067)
Provides power failure capacity for the IPhone IP keysets. This allows a user to make or receive an out-
side call using the central ofÞce if an IP keyset is unable to make or receive a call using the LAN.
● IP Call Recording Adapter (ADA2) (P/N 0890066)
Using the ADA2 Adapter provides a recording jack connection which provides a connection from
an Aspire IPhone to an external tape recorder or speaker.
The following chart indicates if there are restrictions when combining certain adapters. Select the adapter in
the column and then select the adapter in the row to see if there are any restrictions. For example, using an
APA and APR adapter refers you to restriction 3 (only one voice path provided - adapters can not be used
together)
Adapter Compatibility Restrictions
24DLS IP CTU CTA APR APA ADA ADA2 HF-R PSA
ADA
√
1
√ √ √ √
25
√
5
ADA2
5 555555555
APA
√
1
√ √
32
√
5
√
5
APR
√
16
√
23
√
565
CTA
√
142
√ √ √
5
√
5
CTU
√
1246
√ √
565
IP
1 2111115
√
5
HF-R
√
16
√
6
√ √
525
PSA
5 555555555
24DLS
21
√ √ √ √ √
5
√
5
