SSA graphical user interface 14
o Options and information pertinent to the task, after a task is selected
Status Messages—This panel provides the following information and functionality:
o Status icons (critical, warning, and informational) with the number of individual alerts for each
category
o A view all status messages link that displays device-specific alerts in a pop-up window
Controller Configuration Summary—This panel provides a summary of the following elements:
o Data arrays
o Data logical drives
o Data drives
o Unassigned drives
o Spare drives
o A View more details link that displays more information in a pop-up window
Port settings—This panel provides more information about the drives attached to the controller. The
values vary according to the controller and include Mixed RAID and HBA mode.
For a list of possible tasks that are available on the Configure screen, see "Configuration tasks."
Diagnostics screen
To access this screen, either click a device under Diagnostics in the quick navigation menu, or select an
available device from the Home screen, and then click Diagnose under the available options.
From the Diagnostics screen, you can run one of the following reports:
Array Diagnostics Report
SmartSSD Wear Gauge Report
When selecting either report, the available actions on the Actions panel include viewing the report or saving
the report.
