NEC PA653UL User Manual

136
5. Using On-Screen Menu
[OTHERS]
DATE TIME PROJECTOR NAME
MODEL NO. SERIAL NUMBER
LENS ID
[CONDITIONS]
INTAKE TEMPERATURE EXHAUST TEMPERATURE
ATMOSPHERIC PRESSURE INSTALLATION POSITION
X-AXIS Y-AXIS
Z-AXIS
About the X-AXIS, Y-AXIS and Z-AXIS CONDITIONS
* Arrow direction of the Z-AXIS in the gure represents the top of the projector.
X-AXIS ������������������� Display the projector image at an angle of −100 – +100
degrees to the horizontal in the X-axis direction�
X-AXIS value of
the projector
Horizontal plane
X-axis
Gravity direction
Y-AXIS ������������������� Display the projector image at an angle of −100 – +100
degrees to the horizontal in the Y-axis direction�
Y-AXIS value of
the projector
Horizontal plane
Y-axis
Gravity direction
