8. Appendix

❷ Compatible Input Signal List

HDMI/HDBaseT

Signal Resolution ( dots ) Aspect Ratio Refresh Rate ( Hz )

VGA 640 × 480 4 : 3 60/72/75/85/iMac

SVGA 800 × 600 4 : 3 56/60/72/75/85/iMac

XGA 1024 × 768 4 : 3 60/70/75/85/iMac

HD 1280 × 720 16 : 9 60

WXGA

1280 × 768 15 : 9 60

1280 × 800 16 : 10 60

Quad-VGA 1280 × 960 4 : 3 60

SXGA 1280 × 1024 5 : 4 60

FWXGA

1360 × 768 16 : 9 60

1366 × 768 16 : 9 60

SXGA+ 1400 × 1050 4 : 3 60

WXGA+ 1440 × 900 16 : 10 60

WXGA++ 1600 × 900 16 : 9 60

WSXGA+ 1680 × 1050 16 : 10 60

UXGA 1600 × 1200 * 4 : 3 60

Full HD 1920 × 1080 * 16 : 9 60

WUXGA 1920 × 1200 * 16 : 10 60 (Reduced Blanking)

2K 2048 × 1080 17 : 9 60

WQHD

iMac 27"

2560 × 1440 16 : 9 60

WQXGA 2560 × 1600 16 : 10 60 (Reduced Blanking)

3840 × 2160 16 : 9 24/25/30/50/60

4096 × 2160 17 : 9 24/25/30/50/60

HDTV(1080p) 1920 × 1080 * 16 : 9 24/25/30/50/60

HDTV(1080i) 1920 × 1080 * 16 : 9 48/50/60

HDTV (720p) 1280 × 720 16 : 9 50/60

SDTV (480p) 720/1440 × 480 4:3 / 16:9 60

SDTV (576p) 720/1440 × 576 4:3 / 16:9 50

SDTV (480i) 1440 × 480 4:3 / 16:9 60

SDTV (576i) 1440 × 576 4:3 / 16:9 50

DisplayPort

Signal Resolution ( dots ) Aspect Ratio Refresh Rate ( Hz )

VGA 640 × 480 4 : 3 60

SVGA 800 × 600 4 : 3 60

XGA 1024 × 768 4 : 3 60
