161

8. Appendix

INPUT

FOCUS SHIFT

EXIT

ZOOM

ENTER

L-CALIB.

HOME

POSITION

494 (19.4)

580 (22.8)

208 (8.2)

205 (8.1)

125 (4.9)

250 (9.8)

200 (7.9)

56.5 (2.2)

490 (19.3)

❹ Cabinet Dimensions

Lens center

Unit: mm (inch)
