1. Introduction
❷ Introduction to the Projector
This section introduces you to your new projector and describes the features and controls.
General
• Liquid crystal type high brightness/high resolution projector
Model Brightness Resolution Aspect Ratio
PA803UL 8000 lm WUXGA (1920 × 1200) 16:10
PA703UL 7000 lm WUXGA (1920 × 1200) 16:10
PA653UL 6500 lm WUXGA (1920 × 1200) 16:10
Light source · Brightness
• A long-life laser diode is equipped in the light module
The product can be operated at low cost because the laser light source can be used for a long time without requir-
ing replacement or maintenance.
• Brightness can be adjusted within a wide range
Unlike with ordinary light sources, the brightness can be adjusted from 30 to 100% in 1% increments.
• [CONSTANT BRIGHTNESS] mode
Brightness normally decreases with use, but by selecting [CONSTANT BRIGHTNESS] mode, sensors inside the
projector detect and automatically adjust the output, thereby maintaining constant brightness throughout the life
of the light module.
However, if brightness output is set at the maximum, brightness will decrease with use.
Installation
• Wide range of optional lenses selectable according to the place of installation
This projector supports three types of optional lenses, providing a selection of lenses adapted to a variety of places
of installation and projection methods.
In addition, the lenses can be mounted and removed in one touch.
Note that no lens is mounted upon shipment from the factory. Please purchase optional lenses separately.
• Motorized lens control function for easily adjusting the position of the projected image
The position of the projected image (lens shift), Zoom, and Focus can be adjusted by buttons either on the control
panel on the side face of the cabinet or the remote control.
• This projector can be installed universally in every angle
For controlling ne inclination, use the tilt foot. Install an appropriate metal and a stand that has enough strength
to support the projector for controlling the installation angle.
Videos
• Wide range of input/output terminals (HDMI, DisplayPort, HDBaseT, etc.)
The projector is equipped with a variety of input/output terminals: HDMI (input × 2), DisplayPort, HDBaseT (input
x 1, output x 1), computer (analog), etc.
The projector’s HDMI input, DisplayPort input terminals and HDBaseT Ports support HDCP.
• HDMI and HDBaseT support HDCP 2.2/1.4
• DisplayPort supports HDCP 1.3
• Simultaneous display of 2 images (PIP/PICTURE BY PICTURE)
Two images can be projected simultaneously with a single projector.
There are two types of layouts for the two images: “picture-in-picture” in which a sub-picture is displayed on the
main picture, and “picture-by-picture” in which the main and sub pictures are displayed next to each other.
