149
6. Connecting to Other Equipment
Reference drawings
* The drawing showing the dimensional requirements is not an actual stand design drawing.
[Side View] [Front View]
Screw holes for 4 - M4 use
Tilt foot (remove)
130 or
greater**
200
Horizontal adjuster
Exhaust
Intake air
Intake airRear foot
250
** Please refer to the previous page.
