NEC PH1000U - Control Panel;Indicator Section

6
1. Introduction
Control Panel/Indicator Section
1. (POWER) Button (→page17,31)
2. POWER Indicator (→page17,31,228)
3. STATUSIndicator(→page228)
4. LAMP 1 and LAMP 2 Indicators (→page185,228)
5. TEMP.Indicator(→page229)
6. SHUTTERIndicator(→page229)
7. SOURCE Button (→page20)
8. AUTO ADJ. Button (→page30)
9. 3DREFORMButton(→page40)
10.ORIENTATION/CALIBRATIONButton(→page17,19)
11.SHUTTER/HOMEPOSITIONButton(→page24,34)
NOTE: The “home position” for lens shift position is not the center position of the adjustable lens shift range. The home position
should be used for lens installation.
12. MENU Button (→page100)
13. Buttons (→
page100)
14. ENTER Button (→page100)
15.EXITButton(→page100)
16.LENSSHIFT Buttons (→page24)
17.FOCUS+/−Buttons(→page26)
18.ZOOM+/−Buttons(→page27)
19. Light button
 Illuminatesthecontrolpanelandtheterminalpanel.
219 3 4 5 6
1
12 13 1514 16
7 8 9 10 11
17 18
