NEC PH1000U - Adjusting the Vertical Position of a Projected Image (Lens Shift)

24
2. Projecting an Image (Basic Operation)
Adjusting the vertical position of a projected image (Lens shift)
NOTE:
• ThelensshiftfunctionisnotavailableontheprojectorwithNP25FL(xedfocus)lensinstalled.
 Returnthelensshiftpositiontothehomepositionbeforeinstallingthelenstotheprojector.
• Shiftingthelenstothemaximumintwodirectionscombinedwillcausetheedgesoftheimagetobecomedarkorwillcause
some shadows.
Adjusting with buttons on the cabinet
1. PressoneoftheLENSSHIFT▼▲◀▶buttons.
2. UsetheLENSSHIFT▼▲◀▶buttonstomovetheprojectedimage.
Returningthelensshiftpositiontothehomeposition
PressandholdtheSHUTTER/HOMEPOSITIONbuttonfor2secondstoreturnthelensshiftpositiontothehome
position(nearlycenterposition)
