23
2. Projecting an Image (Basic Operation)
4. Rotateeachofthetiltfeettoadjusttheheightwhilekeepingtheprojectorlevelwiththeoor/ceilingand
perpendiculartothescreenwhenviewedfromtheside.
To raise the front side of the projector, extend the left and right tilt feet.
To lower the front side of the projector, extend the rear foot.
 Adjustablerange:2°
Screen
90°
Lower
Raise
Front tilt foot
NOTE:
• Donotlengtheneachofthetiltfeetanymorethan13mm/0.51".Theforceofdoingsomaycausethetiltfoottocomeoff,result-
ing in damage to the projector.
• Donotusethetiltfeetforanypurposeotherthanadjustingtheprojector’sprojectionangle.
Do not attempt to carry or mount the projector using the tilt feet. Doing so may result in damage to the projector or personal
injury.
