2. Projecting an Image (Basic Operation)
CAUTION
• Performtheadjustmentfrombehindorfromthesideoftheprojector.Adjustingfrom
thefrontcouldexposeyoureyestostronglightwhichcouldinjurethem.Therear
ventsoftheprojectormaybecomeheatedduringnormalprojectoroperation.Use
cautionwhenadjustingthetiltfootontherearside.
• Keephandsawayfromthelensmountingportionwhilethelensshiftisinoperation.
Failuretodosocouldresultinhandsbeingpinchedbythemovinglens.
Tilting the projector
Theprojectormustbeplacedsquaretothescreenotherwisekeystonedistortionmayappearonthescreen.Thissec-
tionprovidesexplanationonhowtoplacetheprojectorperpendiculartothescreenwhenviewedfromtheside.
1. Lowerthefrontandbacktiltfeet.
2. Usethehorizontaladjustmentknobtonelytilttheprojectorsothattheprojectorissettobeparallelwith
thescreen.
 Makesurethatthetopedgeoftheimageisparallelwiththebottomedgeoftheimage.
 Adjustablerange:4°
Screen
Parallel
Clockwise
Counter-
clockwise
Horizontaladjustmentknob
3. Rotatethetwofronttiltfeettoadjusttheheighttokeeptheprojectorlevelsothatthetopedgeofthescreen
isparallelwiththetopedgeoftheprojectedimage.
 Adjustablerange:1.8°
Screen
Parallel
Lower
Raise
Front tilt foot
