2. Projecting an Image (Basic Operation)
 Adjusting the Picture Size and Position
Usethehorizontaladjustmentknobandadjustabletiltfeettonelytilttheprojector;usetheLENSSHIFT,ZOOM,
andFOCUSbuttonstoadjustthepicturesizeandposition.
Inthischapterdrawingsandcablesareomittedforclarity.
Tiltingtheprojector
[Horizontaladjustmentknob/Tiltfeet]
Adjustingtheprojectedimage’sverticalandhorizontal
position
[Lensshift]
(→ page 22) (→ page 24)
Adjustingthefocus
[Focus]
Finelyadjustingthesizeofanimage
[Zoom]
(→ page 26) (→ page 27)
Adjustingthekeystonecorrection
[Keystone]
(→ page 28)
TIP:
• Built-intestpatternscanbeconvenientlyusedforadjustingthepicturesizeandposition.(→ page 105)
