NEC PH1000U - Connecting Your Computer;Connecting the Supplied Power Cord

13
2. Projecting an Image (Basic Operation)
 Connecting Your Computer/Connecting the Supplied Power
Cord
NOTE:
• Installalensbeforeperformingthefollowingsteps.(→ page 163)
1. Connectyourcomputertotheprojector.
 Thissectionwillshowyouabasicconnectiontoacomputer.Forinformationaboutotherconnections,see“(2)
MakingConnections”onpage166.
 Connectthecomputercable(VGA)betweentheprojector’sCOMPUTER1INconnectorandthecomputer’sport
(miniD-Sub15Pin).Turntwothumbscrewsofbothconnectorstoxthecomputercable(VGA).
2. Connectthesuppliedpowercordtotheprojector.
WARNING:TOPREVENTFIREORSHOCK,DONOTEXPOSETHISUNITTORAINORMOISTURE.
DONOTUSETHISUNIT’SPLUGWITHANEXTENSIONCORDORINANOUTLETUNLESSALLTHEPRONGS
CANBEFULLYINSERTED.
• UsetheVOLTAGESELECTswitchaccordingtothevoltagebeingused.Select“100V”for100to130Vand“200V”
for200to240V.
 ImportantInformation:
• Whenplugginginorunpluggingthesuppliedpowercord,makesurethatthemainpowerswitchispushedto
the off [O] position. Failure to do so may cause damage to the projector.
• Donotuseathree-phasepowersupply.Doingsomaycausemalfunction.
 Firstconnectthesuppliedpowercord’sthree-pinplugtotheACINoftheprojector,andthenconnecttheother
plug of the supplied power cord in the wall outlet.
COMPUTER 1 IN
Makesurethattheprongsarefullyinsertedinto
boththeACINandthewalloutlet.
Main power switch
To wall outlet
Using the Supplied Power Cords
Selectthepowercordsuitableforyourcountryorregion.
ForEurope/Asia/SouthAmerica ForNorthAmerica
(120V) (200V)
(→page225)
