42
3. Convenient Features
Theadjustablerangesfor3DReformareasfollows:
HORIZONTAL VERTICAL
CORNERSTONE
Max.+/−35°approx. Max.+/−30°approx.
KEYSTONE
* Thefollowingareconditionsunderwhichthemaximumangleisachieved:
• WhentheNP27ZLlensisused
• Whenthelensshiftissettothecenter
 Whenthelensshiftisusedandyettheimageisnotdisplayedinthecenterofthescreen,theadjustablerange
willbeincreasedordecreased.
• Imageisprojectedinmaximumwidewiththezoom
NOTE:
• Evenwhentheprojectoristurnedon,thelastusedcorrectionvaluesareapplied.
• IftheCornerstonescreenisunavailable(grayed),pressandholdthe3DREFORMbuttonforaminimumof2secondstoreset
thecurrentcorrectiondata.TheCornerstonefunctionbecomesavailable.
• Therangeofkeystonecorrectionisnotthemaximumtiltangleofprojector.
NOTE:Using3DReformcorrectioncancausetheimagetobeslightlyblurredbecausethecorrectionismadeelectronically.
