54
3. Convenient Features
② Adjust [RANGE] and [POSITION] to determine an area of overlapped edges of images
projected from each projector.
[RANGE]
(Determine an area of overlapped edges of
images.)
[POSITION]
(Determine the position of overlapped edges of images.)
Greenmarker
Turnon[RIGHT]
Magentamarker
Turn on [LEFT]
Magentamarker
Turningon[MARKER]willdisplaymarkersinmagentaandgreen.
Themagentamarkerisusedfor[RANGE]andgreenonefor[POSITION].
1 Adjust[RANGE].
Use the  or buttontoadjusttheoverlappedarea.
TIP:
• Adjusttooverlaponeprojector’markerwiththeotherprojector’smarker.
2 Adjust[POSITION].
Use the  or buttontoalignoneedgewiththeotheredgeofoverlappedimages.
