Placement of Steam Pipe in Horizontal Duct
35mm Diameter Pipe
1 Pipe
2 Pipes
Illustration 18 - 35 mm Diameter Pipe Placement: Horizontal Duct
51mm Diameter Pipe
1 Pipe
2 Pipes
3 Pipes
Illustration 19 - 51 mm Diameter Pipe Placement: Horizontal Duct
Note: 51 mm steam pipe must be supported on the end by appropriate duct hanger or
strap (supplied by others).
H
10' 
(250mm)
1/3 H
air
air
H
10' 
(250mm)
3' 
(80mm)
8'
(200mm)
6' 
(150mm)
H
10' 
(250mm)
1/3 H
air
H
24' 
(600mm)
1/5 H
2/5 H
8'
(200mm)
air
H
36' 
(900mm)
1/6 H
1/2 H
1/3 H
10'
(250mm)
10'
(250mm)
air
