Neptronic SKE4-E Series - Bill of Material

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 70 -
Bill of Material
Table 16 - Bill of Material
Item
Description
Model
Part Number
1
Evaporation chamber container
SKE4-E05
SW 4222-20
SKE4-E10 to SKE4-E40
SW 4232-20
SKE4-E50 to SKE4-E80
SW 4242-20
SKE4-E90 to SKE4-E120
SW 4253
2
Evaporation chamber cover
SKE4-E05 (1 phase)
SP 4222-1R
SKE4-E05 (3 phases)
SP 4222-2R
SKE4-E10
SP 4232-1R
SKE4-E20 to SKE4-E40
SP 4232-2R
SKE4-E50 to SKE4-E80
SP 4242-1R
SKE4-E90 to SKE4-E100
SP 4251
SKE4-E110 to SKE4-E120
SP 4252
3
Evaporation chamber gasket
SKE4-E05
SP 4222-8
SKE4-E10 to SKE4-E40
SP 4232-8
SKE4-E50 to SKE4-E120
SP 4242-8
4
Heating element
See table below
5
Washer (heating element)
SKE4-E05 to SKE4-E120
SP 1005
6
S/S hex. jam nut (heating element)
SKE4-E05 to SKE4-E120
SP 2330
7
Temperature sensor
See table below
8
High temperature switch (klixon)
SKE4-E05 to SKE4-E120
SP 3036
9
Foam sensor
SKE4-E05
SW FOAMSM-ASSY
SKE4-E10 to SKE4-E80
SW FOAMMED-ASSY
SKE4-E90 to SKE4-E120
SW FOAMSM-ASSY
10
Water level sensor
See table below
11
Water supply valve
SKE4-E05 to SKE4-E120
SP 6009
12
Drain pump
SKE4-E05 to SKE4-E120
SP G4101
13
Drain valve
SKE4-E05 to SKE4-E120
SP 4233-59
14
Disconnect switch
See table below
15
Transformer
See table below
16
Contactor
See table below
17
Alphanumeric display
SKE4-E05 to SKE4-E120
SW SKE4DISPLAY-AS
SKE4-E05W to SKE4-E120W
SW SKE4DISPLAY2
18
Printed circuit board
SKE4-E05 to SKE4-E120
NW SKE4MAINSS
SKE4-E05W to SKE4-E120W
NW SKE4MAINWSS
19
Solid-state relay
SKE4-E05 to SKE4-E120
SP 3102
20
SDU steam dispersion manifold
SDU4-1
SW 4134
SDU4-2
SW 4135
SDU4-3
SW 4136
21
SDU relay
SDU4-1, SDU4-2 & SDU4-3
SP 3114
22
SDU fan
SDU4-1
SP 3012
SDU4-2
SP 3009
SDU4-3
SP 3014
23
SDU transformer
See table below
24
Fuse inside SDU
SDU4-1, SDU4-2 & SDU4-3
SP 5105
25
SDU airflow switch
SDU4-1, SDU4-2 & SDU4-3
SW PSA1
26
SDU plastic grill
SDU4-1, SDU4-2 & SDU4-3
SP 4131-11
