Neptronic SKE4-E Series - Visual Identification; Humidifier Left Side View; Humidifier Right Side View

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 5 -
Visual Overview
Left Side
Steam Outlet
Heating
Element
Connectors
Controller
Water Level
Sensor
Manual Drain
Valve
Water Inlet
Disconnect
Switch
Right Side
Access Door to
Low Voltage
Compartment
Printed Circuit
Board
Evaporation
Chamber
Access Panel to
High Voltage
Compartment
Rail Guide
Illustration 1 - Overview of the Humidifier (SKE4-E05 to E80)
