R900 cellular endpoint Wall and Pit Installation and
39
Appendix B: Field Manager
Field Manager is an Android and iOS application that can communicate with a cellular
endpoint
during the installation, troubleshooting, and maintenance of the MIU. The MIU
Manager provides the following functionality checks on the MIU:
• LTE Connection Status
The Manager is compatible with iOS version X.X and Android Y using either an iPhone or iPad.
LTE Connection Status
The LTE Connection Status screen provides a snapshot of the current configuration of
the R900 Cellular Endpoint that is being searched. This information provided is
below:
• Endpoint Status (4 possible states based on signal quality: Excellent, Good, Fair, Poor)
• Signal quality (RSRP and RSRQ)
• Last meter reading
• Last call in time
Additionally, users can open a collapsible section and review additional information
for their R900 cellular endpoint as listed below:)
• Mode
• Reporting Interval
• Recording Interval
• Reading Interval
• CMIU Clock
• Last RSRP
• Last RSRQ
• Firmware Rev.
• Bootloader Rev.
• Config Rev.
• Register ID of the connected register
Error Messaging
Given a user is attempting to search for a R900 cellular endpoint, but cannot return
their details, there are two possible error scenarios that can occur.
1. If the user’s mobile device does not have service at the time of searching, the
user will see a message stating, “ No network connection. Try again later.”
2. If the user is searching for an endpoint and nothing can be returned, the user
will see a message stating, “Cannot find MIU. Please try swiping again or
moving to a new location to try connection again”
< Image Placeholder>
Figure 46 – R900 cellular endpoint Status
