NETGEAR GC510P User Manual

Mount the Switch to a Pole or Another Surface
You can use an off-the-shelf 75 mm VESA standard mount to secure the switch to a pole or another surface.
The bottom panel of the switch provides four mount holes that are VESA-compliant.
Install the Switch in a Rack
To install the switch in a rack, you need the 19-inch rack-mount kit supplied with the switch.
To install the switch in a rack:
1. Attach the supplied mounting brackets to the side of the switch.
2. Insert the screws provided in the product package through each bracket and into the bracket mounting
holes in the switch.
3. Tighten the screws with a No. 2 Phillips screwdriver to secure each bracket.
4. Align the mounting holes in the brackets with the holes in the rack, and insert two pan-head screws with
nylon washers through each bracket and into the rack.
5. Tighten the screws with a No. 2 Phillips screwdriver to secure mounting brackets to the rack.
Optional Step 5: Install SFP Transceiver Modules
The following optional procedure describes how to install an optional SFP transceiver module into one of
the SFP ports of the switch.
Installation
31
Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports

NETGEAR GC510P Specifications

General

Switch type	Managed
Quality of Service (QoS) support	Yes
Console port	RJ-45
Power connector	DC-in jack
Installed SFP modules quantity	2
Installed SFP+ modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	-
MAC address table	- entries
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Total Power over Ethernet (PoE) budget	134 W
Operating temperature (T-T)	0 - 45 °C

Weight and Dimensions

Depth	188 mm
Width	314 mm
Height	44 mm
Weight	2010 g
