NETGEAR M4300 Intelligent Edge Series User Manual

Hardware descriptions, M4300 series full
10G models
This section describes the switch hardware features for the following full 10G models:
•
M4300-16X. Switch model with sixteen 10G PoE+ copper ports
•
M4300-8X8F. Switch model with eight 10G copper ports and eight 10G fiber ports
•
M4300-12X12F. Switch model with twelve 10G copper ports and twelve 10G fiber
ports
•
M4300-24X24F. Switch model with twenty-four 10G copper ports and twenty-four
10G fiber ports
Front panel, M4300 series full 10G models
The full 10G models provide either a port configuration of sixteen independent
10GBASE-T autosensing ports or a port configuration of eight, twelve, or twenty-four
independent 10GBASE-T autosensing ports and eight, twelve, or twenty-four
independent 10GBASE-X SFP+ ports.
Model M4300-16X
The following figure illustrates the front panel of half-width model M4300-16X.
Figure 1. Front panel model M4300-16X
DescriptionNumber
Power, PoE Max, and Fan LEDs1
Stack ID LED2
USB port3
RJ-45 RS232 console port4
Stack Master LED5
Hardware Installation Guide15Hardware Overview
M4300 Intelligent Edge Series Fully Managed Stackable Switches

NETGEAR M4300 Intelligent Edge Series Specifications

General

Switch Type	Managed
Form Factor	Rack-mountable
Layer 3 Features	Static routing, RIP, OSPF, VRRP
Model	NETGEAR M4300 Intelligent Edge Series
Ports	Varies by model
PoE	Available on some models
Stacking	Yes
Redundancy	Redundant power supplies (on some models)
Management	Web-based, CLI, SNMP
Switching Capacity	Varies by model
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
Layer 2 Features	VLAN, STP, RSTP, MSTP
Security Features	ACL, 802.1X
Dimensions	Varies by model (see documentation)
Weight	Varies by model (see documentation)
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Power Supply	Internal
Warranty	Lifetime
