NETGEAR M4300 Intelligent Edge Series User Manual

From left to right, the back panel of model M4300-8X8F provides the following
components:
•
Fixed fans for front-to-back air flow.
•
Modular bay in which an APS250W power supply unit (PSU) is installed.
Model M4300-12X12F
The following figure illustrates the back panel of half-width model M4300-12X12F.
Figure 7. Back panel model M4300-12X12F
DescriptionNumber
RJ-45 RS232 console port1
OOB port with port LEDs2
PSU with AC connector3
From left to right, the back panel of model M4300-12X12F provides the following
components:
•
One out-of-band 1G Ethernet port.
•
One RJ-45 RS232 (115200, N, 8, 1) console port.
•
Fixed fans for front-to-back air flow.
•
Modular bay in which an APS250W power supply unit (PSU) is installed.
Model M4300-24X24F
The following figure illustrates the back panel of full-width model M4300-24X24F.
Figure 8. Back panel model M4300-24X24F
Hardware Installation Guide20Hardware Overview
M4300 Intelligent Edge Series Fully Managed Stackable Switches

NETGEAR M4300 Intelligent Edge Series Specifications

General

Switch Type	Managed
Form Factor	Rack-mountable
Layer 3 Features	Static routing, RIP, OSPF, VRRP
Model	NETGEAR M4300 Intelligent Edge Series
Ports	Varies by model
PoE	Available on some models
Stacking	Yes
Redundancy	Redundant power supplies (on some models)
Management	Web-based, CLI, SNMP
Switching Capacity	Varies by model
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
Layer 2 Features	VLAN, STP, RSTP, MSTP
Security Features	ACL, 802.1X
Dimensions	Varies by model (see documentation)
Weight	Varies by model (see documentation)
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Power Supply	Internal
Warranty	Lifetime
