NETGEAR M4300 Intelligent Edge Series User Manual

Table 1. LEDs of the full 10G models (Continued)
DesignationLED
Left side speed LED:
Off. No link is established on the port.
Solid green. The port established a 1000 Mbps link.
Solid yellow. The port established a 10 or 100 Mbps link.
OOB Ethernet port LEDs
(two LEDs per port)
Right side activity and link LED:
Off. No link is established on the port.
Solid green. The port established a link.
Blinking green. The port is transmitting or receiving packets.
Off. No SFP module link is established on the fiber port.
Solid green. The fiber port established a 10 Gbps link.
Blinking green. The fiber port is transmitting or receiving packets at 10 Gbps.
Solid yellow. The fiber port established a 1 Gbps link.
Blinking yellow. The fiber port is transmitting or receiving packets at 1 Gbps.
10GBASE-X SFP+ port
LED
(one LED per port)
Off. No link is established on the copper port.
Solid green. The copper port established a 10 Gbps link.
Blinking green. The copper port is transmitting or receiving packets at 10 Gbps.
Solid yellow. The copper port established a 1 Gbps or 100 Mbps link.
Blinking yellow. The copper port is transmitting or receiving packets at 1 Gbps or 100
Mbps.
Non-PoE models
10GBASE-T RJ45 port
LED
(one LED per port)
PoE model (M4300-16X), right side PoE status LED:
Off. A PD is not connected to the port.
Solid green. A PoE-powered device (PD) is connected and the port is supplying power
successfully.
Solid yellow. Indicates one of the following failures, which prevents the port from
supplying power:
•
A short circuit occurred on the PoE power circuit.
•
The PoE power demand exceeds the available power.
•
The PoE current exceeds the PD’s classification.
•
An out-of-proper-voltage band condition occurred.
PoE model (M4300-16X)
10GBASE-T RJ45 port
LEDs
(two LEDs per ports)
PoE model (M4300-16X), left side speed, activity, and link LED:
Off. No link is established on the copper port.
Solid green. The copper port established a 10 Gbps link.
Blinking green. The copper port is transmitting or receiving packets at 10 Gbps.
Solid yellow. The copper port established a 5 Gbps, 2.5 Gbps, 1 Gbps, or 100 Mbps
link.
Blinking yellow. The copper port is transmitting or receiving packets at 5 Gbps,
2.5 Gbps, 1 Gbps, or 100 Mbps.
Hardware Installation Guide22Hardware Overview
M4300 Intelligent Edge Series Fully Managed Stackable Switches

NETGEAR M4300 Intelligent Edge Series Specifications

General

Switch Type	Managed
Form Factor	Rack-mountable
Layer 3 Features	Static routing, RIP, OSPF, VRRP
Model	NETGEAR M4300 Intelligent Edge Series
Ports	Varies by model
PoE	Available on some models
Stacking	Yes
Redundancy	Redundant power supplies (on some models)
Management	Web-based, CLI, SNMP
Switching Capacity	Varies by model
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
Layer 2 Features	VLAN, STP, RSTP, MSTP
Security Features	ACL, 802.1X
Dimensions	Varies by model (see documentation)
Weight	Varies by model (see documentation)
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Power Supply	Internal
Warranty	Lifetime
