NETGEAR M4300 Intelligent Edge Series User Manual

Model M4300-52G-POE+
The following figure illustrates the back panel of full-width model M4300-52G-POE+.
Figure 14. Back panel model M4300-52G-POE+
DescriptionNumber
RJ-45 RS232 console port1
RPS interface2
PSU1 with AC connector3
Bay for PSU24
From left to right, the back panel of model M4300-52G-POE+ provides the following
components:
•
One RJ-45 RS232 (115200, N, 8, 1) console port.
•
One redundant power supply (RPS) interface.
•
Fixed fans for front-to-back air flow.
•
Modular bay in which an APS550W power supply unit (PSU) or APS1000W PSU is
installed, depending on the product ordered.
•
Second modular bay for an optional second PSU.
Hardware Installation Guide28Hardware Overview
M4300 Intelligent Edge Series Fully Managed Stackable Switches

NETGEAR M4300 Intelligent Edge Series Specifications

General

Switch Type	Managed
Form Factor	Rack-mountable
Layer 3 Features	Static routing, RIP, OSPF, VRRP
Model	NETGEAR M4300 Intelligent Edge Series
Ports	Varies by model
PoE	Available on some models
Stacking	Yes
Redundancy	Redundant power supplies (on some models)
Management	Web-based, CLI, SNMP
Switching Capacity	Varies by model
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
Layer 2 Features	VLAN, STP, RSTP, MSTP
Security Features	ACL, 802.1X
Dimensions	Varies by model (see documentation)
Weight	Varies by model (see documentation)
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Power Supply	Internal
Warranty	Lifetime
