Manage and Monitor the Switch
62
ProSAFE Gigabit Web Managed (Plus) Switches
Manage Power Saving Options
Note: Power saving options are available on models GS105Ev2, GS105PE,
GS116Ev2, JGS516PE, JGS524Ev2, and JGS524PE.
Depending on the power saving options that your switch model provides, you can manage
the IEEE 802.3az Energy Efficient Ethernet (EEE) function, cable length power saving, or
link-up and link-down power saving, or a combination of these features:
Short Cable Power Saving. Dynamically detects and adjusts power that is required for
the detected cable length.
Link-Down Power Saving. Reduces the power consumption considerably when the
network cable is disconnected. When the network cable is reconnected, the switch
detects an incoming signal and restores normal power.
EEE. Combines the Energy Efficient Ethernet (EEE) 802.3 MAC sublayer with the
100BASE-TX and 1000BASE-T physical layers to support operation in Low Power Idle
(LPI) mode. When LPI mode is enabled, systems on both sides of the link can disable
portions of their functionality and save power during periods of low link utilization.
Use Browser-Based Access to Enable Power Saving Mode
To enable the power saving options:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired network connection, or connect directly to a switch that is
off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the Switch Using a Web
Browser on page 7.
The login window opens.
4. Enter the switch’s password in the password field.
The switch’s default password is password.
The Switch Information page displays.
5. Select System > Management > Power Saving Mode.
