Manage Network Settings
21
ProSAFE Gigabit Web Managed (Plus) Switches
By default, if you enable IGMP snooping, snooping occurs on VLAN 1. However, you can
enable snooping on any VLAN:
• For port-based VLANs, you can enter a VLAN ID from 1 to the maximum number that
you switch supports (5, 8, 16, or 24).
• For 802.1Q-based VLANs, you can enter a VLAN ID from 1 to 4094.
9. Click the APPLY button.
Your settings are saved.
Set Up Static Link Aggregation Groups
Note: Static link aggregation (port trunking) is supported on models GS116E,
JGS516PE, JGS524E, and JGS524PE.
Link aggregation groups (LAGs) allow you to combine multiple Ethernet links into a single
logical link. Network devices treat the aggregation as if it were a single link, which increases
fault tolerance and load sharing. The number of LAGs that the switch supports depends on
the model. Configure LAG membership before you enable the LAG.
Note: The switch does not support IEEE 802.3ad Link Aggregation or Link
Aggregation Control Protocol (LACP) groups. The switch supports
manual static LAGs only.
Use Browser-Based Access to Specify LAG Membership and
Enable LAGs
You must set up LAG membership before you can enable LAGs.
To specify LAG membership and enable a LAG:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired network connection, or connect directly to a switch that is
off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the Switch Using a Web
Browser on page 7.
The login window opens.
4. Enter the switch’s password in the password field.
