Storage Central Turbo Model SC101T and Storage Central Model SC101 User Manual
3-2
v1.0, December 2006
To use the wizard to create a drive, follow these steps:
5. You will be asked if you want to mirror the drive and if the drive will be shared.
• Mirroring: Requires two hard disks installed in the Storage Central. Duplicates all data
for the new drive that you are creating on the other hard disk.
• Sharing: Allows more than one computer to access the data at the same time.
6. When prompted, enter a password if you plan to use security (recommended).
1. Click the icon, select Wizard Setup, and
then click Next.
2. Select Create a new drive, and then click
Next.
3. Select which physical hard disk in the
Storage Central to store data for this PC.
• The physical capacity of the disk is
shown in the disk list.
• If you have two disks that are the same
size, you can remove one disk, and give
the remaining one a name. Also, name
the second disk when you reinsert it.
See “Ejecting a Hard Disk from the
Storage Central Turbo SC101T” in
Chapter 5.
4. Enter the name and capacity for the drive.
The drive capacity must be at least 2 GB for
the SC101T or 1 GB for the SC101.
Figure 3-1
Note: The mirror option only can be selected when you create a new drive. After the
drive has been created you cannot add mirroring.
Note: If you want to use the shared drive from other PCs, then after you create
this drive, you must run the Storage Central Manager utility on those PCs
and attach the drive to each of them.
