Storage Central Turbo Model SC101T and Storage Central Model SC101 User Manual
5-4
v1.0, December 2006
Locating the Serial Number
You may need to enter the serial number in order to install the back up software. The serial number
for the Storage Central is on the product label located on the rear panel. The serial number is also
on the box.
Ejecting a Hard Disk from the Storage Central Turbo SC101T
To eject a hard disk from the Storage Central, follow these steps:
3. Remove the hard disk and replace the front panel.
Warning: To avoid damaging your hard disks, turn off or unplug the power cord from
the Storage Central before ejecting the disks.
1. Slide up the front panel and remove it to
uncover the disk.
2. On the back of the Storage Central, push
down the eject lever as shown below:
Figure 5-2
Figure 5-3
