NETGEAR WGU624 User Manual

Reference Manual for the Double 108 Mbps Wireless Firewall Router WGU624
A-2 Technical Specifications
M-10153-01
Electromagnetic Emissions
Meets requirements of: FCC Part 15 Class B
EN 55 022 (CISPR 22), Class B
C-Tick N10947
Interface Specifications
The router incorporates Auto Uplink
TM
technology which
eliminates the need for crossover cables.
LAN: 10BASE-T or 100BASE-Tx, RJ-45, autosensing and
capable of full-duplex or half-duplex operation
WAN: 10BASE-T or 100BASE-Tx, RJ-45, autosensing and
capable of full-duplex or half-duplex operation
Wireless
Radio Data Rates: 1, 2, 5.5, 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
Auto Rate Sensing
Frequency: 2.4/5.0 GHz
Data Encoding: 802.11b/g 2.4 GHz to 2.5 GHz CCK and OFDM Modulation
802.11a
* 5.15~5.25 GHz (lower band)
* 5.25~5.35 GHz (middle band)
* 5.725~5.825 GHz (hi-band)
Maximum Computers Per
Wireless Network:
Limited by the amount of wireless network traffic generated
by each node. Typically up to 30 nodes.
Operating Frequency Ranges: 2.412~2.462 GHz (US) 2.457~2.462 GHz (Spain)
2.412~2.484 GHz (Japan) 2.457~2.472 GHz (France)
2.412~2.472 GHz (Europe ETSI)
Encryption: 40-bit (also called 64-bit), 128-bit, and 152-bit WEP data
encryption, WPA encryption

NETGEAR WGU624 Specifications

Power

power adapter voltage	5V
power adapter current	2.8 A

Networking and Connectivity

network standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11a
ports	Five10/100 (1 Internet, & 4 LAN) ports
operating frequencies	2.4 GHz and 5.0 GHz

Weight and Dimensions

dimensions	6.9 x 1.1 x 4.7 in (175.3 x 27.94 x 119.4 mm)
weight	.7 lbs (.3 kg)
max range (indoor)	400 ft
