NETGEAR WGU624 User Manual

Reference Manual for the Double 108 Mbps Wireless Firewall Router WGU624
3-4 Connecting the Router to the Internet
M-10153-01
Connecting the WGU624
This section provides instructions for connecting the Double 108 Mbps Wireless Firewall Router
WGU624. Also, the Double 108 Mbps Wireless Router WGU624 Resource CD included with
your router contains an animated Installation Assistant to help you through this procedure.
Connecting the Wireless Router
Follow the steps below to connect your router to your network. You can also refer to the Double
108 Mbps Wireless Router WGU624 Resource CD included with your router which contains an
animated Installation Assistant to help you through this procedure.
1. CONNECT THE WIRELESS ROUTER, THE COMPUTER, AND THE MODEM.
a. Turn off your computer and your cable or DSL modem.
b. Locate the Ethernet cable (Cable 1 in the diagram below) that connects your PC to the
modem.
c. Disconnect the cable at the computer end only, point A in the diagram.
Figure 3-1: Disconnect the Ethernet cable from the computer
d.
Look at the label on the bottom of the wireless router. Locate the Internet port. Securely
insert the Ethernet cable from your modem (Cable 1 in the diagram below) into the
Internet port of the wireless router as shown in point B in the diagram below.
PRGHP
&DEOH
,QWHUQHW
FRPSXWHU
A

NETGEAR WGU624 Specifications

Power

power adapter voltage	5V
power adapter current	2.8 A

Networking and Connectivity

network standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11a
ports	Five10/100 (1 Internet, & 4 LAN) ports
operating frequencies	2.4 GHz and 5.0 GHz

Weight and Dimensions

dimensions	6.9 x 1.1 x 4.7 in (175.3 x 27.94 x 119.4 mm)
weight	.7 lbs (.3 kg)
max range (indoor)	400 ft
