NETGEAR WGU624 User Manual

Reference Manual for the Double 108 Mbps Wireless Firewall Router WGU624
Connecting the Router to the Internet 3-5
M-10153-01
Note: Place the WGU624 wireless router in a location which conforms to the “Observing
Performance, Placement, and Range Guidelines” on page 4-1. The stand provided with the
WGU624 provides a convenient, space-saving way of installing the wireless router. Avoid
stacking it on other electronic equipment.
Figure 3-2: Connect the wireless router to the modem
e.
Securely insert the blue cable that came with your wireless router into a LAN port on the
router such as LAN port 4 (point C in the diagram), and the other end into the Ethernet
port of your computer (point D in the diagram).
Figure 3-3: Connect the computers on your network to the router
Your network cables are connected and you are ready to restart your network.
PRGHP
&DEOH
,QWHUQHW
,QWHUQHW
SRUW
URXWHU
B
/$13RUWV

%OXH1(7*($5
&DEOH
,QWHUQHW
PRGHP
URXWHU
FRPSXWHU
C
D

NETGEAR WGU624 Specifications

Power

power adapter voltage	5V
power adapter current	2.8 A

Networking and Connectivity

network standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11a
ports	Five10/100 (1 Internet, & 4 LAN) ports
operating frequencies	2.4 GHz and 5.0 GHz

Weight and Dimensions

dimensions	6.9 x 1.1 x 4.7 in (175.3 x 27.94 x 119.4 mm)
weight	.7 lbs (.3 kg)
max range (indoor)	400 ft
