NETGEAR WGU624 User Manual

Reference Manual for the Double 108 Mbps Wireless Firewall Router WGU624
Wireless Configuration 4-9
M-10153-01
Wireless Security Settings
The following table shows the 11a and 11g security mode and cipher type options:
Instructions on how to configure the security settings are provided in the following sections.
WEP Authentication and Encryption
Restricting wireless access to your network prevents intruders from connecting to your network.
However, the wireless data transmissions are still vulnerable to snooping. Using the WEP data
encryption settings described below will prevent a determined intruder from eavesdropping on
your wireless data communications. Also, if you are using the Internet for such activities as
purchases or banking, those Internet sites use another level of highly secure encryption called SSL.
You can tell if a Web site is using SSL because the Web address begins with HTTPS rather than
HTTP.
Table 4-3. Wireless Security Settings
Security Mode Cipher Type
Open System WEP — 64, 128, or 152 bit encryption
Shared Key WEP — 64, 128, or 152 bit encryption
802.1x none
WPA-PSK AES or TKIP
WPA AES or TKIP

NETGEAR WGU624 Specifications

Power

power adapter voltage	5V
power adapter current	2.8 A

Networking and Connectivity

network standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11a
ports	Five10/100 (1 Internet, & 4 LAN) ports
operating frequencies	2.4 GHz and 5.0 GHz

Weight and Dimensions

dimensions	6.9 x 1.1 x 4.7 in (175.3 x 27.94 x 119.4 mm)
weight	.7 lbs (.3 kg)
max range (indoor)	400 ft
