Reference Manual for the Double 108 Mbps Wireless Firewall Router WGU624
Preparing Your Network C-7
M-10153-01
2. Type winipcfg, and then click OK.
The IP Configuration window opens, which lists (among other things), your IP address, subnet
mask, and default gateway.
3. From the drop-down box, select your Ethernet adapter.
The window is updated to show your settings, which should match the values below if you are
using the default TCP/IP settings that NETGEAR recommends for connecting through a
router or gateway:
The IP address is between 192.168.1.2 and 192.168.1.254
The subnet mask is 255.255.255.0
The default gateway is 192.168.1.1
Configuring Windows NT4, 2000 or XP for IP Networking
As part of the PC preparation process, you may need to install and configure
TCP/IP on each networked PC. Before starting, locate your Windows CD; you may need to insert
it during the TCP/IP installation process.
Install or Verify Windows Networking Components
To install or verify the necessary components for IP networking:
1. On the Windows taskbar, click the Start button, point to Settings, and then click Control Panel.
2. Double-click the Network and Dialup Connections icon.
3. If an Ethernet adapter is present in your PC, you should see an entry for Local Area
Connection. Double-click that entry.
4. Select Properties.
5. Verify that ‘Client for Microsoft Networks’ and ‘Internet Protocol (TCP/IP)’ are present. If
not, select Install and add them.
6. Select ‘Internet Protocol (TCP/IP)’, click Properties, and verify that “Obtain an IP address
automatically is selected.
7. Click OK and close all Network and Dialup Connections windows.
8. Then, restart your PC.

Table of Contents

Other manuals for NETGEAR WGU624

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR WGU624 and is the answer not in the manual?

NETGEAR WGU624 Specifications

Power IconPower
power adapter voltage5V
power adapter current2.8 A
Networking and Connectivity IconNetworking and Connectivity
network standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11a
portsFive10/100 (1 Internet, & 4 LAN) ports
operating frequencies2.4 GHz and 5.0 GHz
Weight and Dimensions IconWeight and Dimensions
dimensions6.9 x 1.1 x 4.7 in (175.3 x 27.94 x 119.4 mm)
weight.7 lbs (.3 kg)
max range (indoor)400 ft
