NETGEAR WGU624 User Manual

Reference Manual for the Double 108 Mbps Wireless Firewall Router WGU624
7-14 Advanced Configuration
M-10153-01
To add or edit a Static Route:
1. Click the Add button to open the Add/Edit menu, shown below.
Figure 7-7. Static Route Add/Edit menu
2.
Type a route name for this static route in the Route Name box under the table. (This is for
identification purposes only.)
3. Select Private if you want to limit access to the LAN only. The static route will not be reported
in RIP.
4. Select Active to make this route effective.
5. Type the Destination IP Address of the final destination.
6. Type the IP Subnet Mask for this destination. If the destination is a single host, type
255.255.255.255.
7. Type the Gateway IP Address, which must be a router on the same LAN segment as the router.
8. Type a number between 1 and 15 as the Metric value. This represents the number of routers
between your network and the destination. Usually, a setting of 2 or 3 works, but if this is a
direct connection, set it to 1.
9. Click Apply to have the static route entered into the table.

NETGEAR WGU624 Specifications

Power

power adapter voltage	5V
power adapter current	2.8 A

Networking and Connectivity

network standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11a
ports	Five10/100 (1 Internet, & 4 LAN) ports
operating frequencies	2.4 GHz and 5.0 GHz

Weight and Dimensions

dimensions	6.9 x 1.1 x 4.7 in (175.3 x 27.94 x 119.4 mm)
weight	.7 lbs (.3 kg)
max range (indoor)	400 ft
