Wireless-N 150 ADSL2+ Modem Router DGN1000 User Manual
5-12 Advanced Configuration
v1.1, January 2010
3. If you make changes, you must click Apply in order for them to take effect.
The WLAN1 settings are based on the selections that you made in the Wireless Settings
screen. (See “Manually Configuring Your Wireless Network” on page 2-4).
Table 5-3. Advanced Wireless Settings
Setting Description
WPS (Push 'N'
Connect)
This radio button is selected by default.
Name (SSID) The service set ID, also known as the wireless network name for WLAN1.
Region The country where the unit is set up for use.
Channel The current channel, which determines the operating frequency.
Wireless AP Indicates if the access point feature is enabled for WLAN1. If disabled, the
Wireless LED on the front panel is off.
Broadcast Name Indicates if the wireless modem router is configured to broadcast its SSID for
WLAN1.
Security Indicates if security is configured on the wireless modem router, and if so,
what type of security is configured.
Router’s PIN • The PIN number that you use on a registrar (for example, from the Network
Explorer on a Vista Windows PC) to configure the wireless modem router’s
wireless settings through WPS. You can also find the PIN on the wireless
modem router's product label.
• The PIN function may temporarily be disabled when the wireless modem
router detects suspicious attempts to break into the wireless modem router’s
wireless settings by using the wireless modem router’s PIN through WPS.
You can manually enable the PIN function by deselecting the Disable
Router’s PIN check box.
Keep Existing Wireless
Settings
• By default, the Keep Existing Wireless Settings check box is cleared. This
allows the modem router to automatically generate the SSID and WPA/
WPA2 security settings when it implements WPS. After WPS is
implemented, the modem router automatically selects this check box so that
your SSID and wireless security settings remain the same if other WPS-
enabled devices are added later.
• If you configure your wireless router settings and security manually, the
Keep Existing Wireless Settings check box will also be enabled. This will
allow you to use WPS (Push 'N' Connect) to connect additional WPS
capable devices to your wireless network using the existing settings.
