4
VMC 1100 User Manual
Chapter 1: Product Introduction
I/O Interface-Rear
• 1x 5pin circular connector for Power/Ignition input
• 1x RJ45 for LAN
• 1x RJ45 for Full RS-232 with 0V/5V/12V power supply (0.5A)
• 1x DB9 (Male) for
- RS-232 (RX/TX) or RS-485
- 1x CAN Bus 2.0
• 1x DB15 (Female) for
- GPS dead reckoning interface (optional)
- 2x PWM, 2x Analog Input, 3x GPO, 3x GPI
Analog Input requirement for Voltages are measured
Channel: 2
Voltage range: 0~38V
Resolution: 8 bit
Analog Input requirement for Frequency, Speed
Square wave
Frequency signal offset voltage range: 0~15VDC
Protection: +/- 500V spike
Frequency signal duty cycle range: 10%~90%
Communication Module
• 1x u-blox NEO-M8N module on board (support GPS/Gloness/QZSS/
Galileo/Beidou) or optional module with Dead Reckoning
• 1x WLAN or Bluetooth module for optional
• 1x WWAN module for optional
Power Management
• Selectable boot-up & shut-down voltage for low power protection
• HW design ready for 8-level delay time on/off at user’s self configuration
• Power on/off ignition, software detectable
• Support S3 and S4 suspend mode; wake on RTC and SMS
Operating System
• Windows 8 Professional, WES8
• Windows 7, WES7
• Linux Fedora (kernel V3.2.0)
Environment
• Operating temperatures: Ambient with air -20°C to 60°C
• Storage temperatures: -30°C to 80°C
• Relative humidity: 10% to 90% (non-condensing)
• Vibration (random): 3g @5~500Hz
• Vibration
Operating: MIL-STD-810G, 514.6 Procedure 1, Category 4
Storage: MIL-STD-810G, 514.6 Procedure 1, Category 24
• Shock
Operating: MIL-STD-810G, Method 516.6, Procedure I, trucks and semi-
trailers= 20g
Crash hazard: MIL-STD-810G, Method 516.6, Procedure V, ground
equipment= 75g
Power Design & Protection
• Load dump and inductive load protection
• Cold cranking protection
• Transient voltage protection
• Electrostatic discharge protection
Standards/Certifications
• EMC
- CE, FCC class B
• Power
- SAE J1113
- SAE J1455
- ISO 7637-2
• Safety
- EN 60950-1 LVD
