Chapter 3: Jumpers and Connectors
ME/RTC Clear Switch
Connector size: 2-pin DIP switch
Connector location: SW1
Input Voltage Control Switch
Connector size: 2-pin DIP switch
Connector location: SW3
Pin Status Function
1-2 ON Clear CMOS/ME
1-2 OFF Normal
Pin Status Function
1-2 OFF 12V
1-2 1 OFF, 2 ON 24V
1-2 On 9-36V
1
O N
2 1
O N
2
