VMC 1100 User Manual
Chapter 3: Jumpers and Connectors
MCU Debug COM Header
Connector size: 1x3 3-pin header, 1.0mm pitch
Connector location: JP1
Pin Definition
1 TX
2 RX
3 GND
MCU Flash Connector
Connector size: 2x4 8-pin header, 1.0mm pitch
Connector location: JP2
17
28
Pin Definition Pin Definition
1 +V3.3ALW 2 MCU_RST#
3 MCU_TRST 4 MCU_TDI
5 MCU_TCK 6 MCU_TMS
7 MCU_TDO 8 GND
13
