Appendix B: Vehicle Power Management Setup
aPPendIx b: vehICle Power management setuP
External Power Output Setting
External +12V and +5V Turn Off SimultaneouslyExternal +12V and +5V Turn On Simultaneously
Advanced
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enable/Disable External Power
Power Management Conguration
** External +5V & +12V Power Setting **
External Power
** Startup & Shutdown Voltage Setting **
Input Voltage
Startup,Shutdown
**Delay Time Setting**
Power On Delay
Power Off Delay
[Turn Off Both]
12 V
[(11.5,10.5)/(23,21)]
External Power
Turn Off Both
Turn On Both
Turn On +5V
Turn On +12V
Advanced
