Chapter 3: Jumpers and Connectors
Internal Connectors and DIP Switch Settings
Pin Definition Pin Definition
1 VGA_+5V 2 VGA_CLK
3 VGA_DATA 4 VGA_VS
5 VGA_HS 6 GND
7 VGA_BLUE 8 VGA_GREEN
9 VGA_RED 10 GND
VGA Connector
Connector size: 1x10 10-pin header, 1.0mm pitch
Connector location: J2
10 1
24
1
Flash/Debug Connector
Connector size: 1x24 24-pin wafer, 1.0mm pitch
Connector location: J1
Pin Definition Pin Definition
1 GND 2 GND
3 EC_KSI5 4 EC_KSI4
5 EC_KSI3 6 EC_KSI2
7 EC_KSI1 8 EC_KSI0
9 GND 10 GND
11 GND 12 GND
13 GND 14 EC_KSO10
15 EC_KSO9 16 EC_KSO8
17 EC_KSO7 18 EC_KSO6
19 EC_KSO5 20 EC_KSO4
21 EC_KSO3 22 EC_KSO2
23 EC_KSO1 24 EC_KSO0
