VMC 1100 User Manual
Chapter 1: Product Introduction
Hardware Specifications
VMC 1100
General
• Cooling System: Fanless
• Enclosure: Plastic PC + ABS
• Mounting: Support VESA 75, stand mounting
• Four SMA type antenna connectors of BT/ Wi-Fi/ WWAN/ GPS
• Power Input: 9~36VDC input with ignition
• Power Consumption: 26W
• Ingress Protection: Front panel IP54
• Dimension: 213mm (W) x 145mm (H) x 50mm (D)
(8.3” x 5.7” x 1.9”)
LCD Panel
• 7-inch TFT LCD panel with LED backlight
• 800 x 480 pixels (WVGA)
• Brightness: 400 cd/m² (typical)
• Contrast ratio: 600:1 (typical)
Touch Screen Sensor
• 4-wire resistant touch
• Anti-glare coating surface
• Transmission rate: 78 ± 3%
CPU & Chipset
• Intel
®
Atom™ Dual Core E3825 1.33GHz
Memory
• 2GB 204-pin DDR3L 1600MHz SO-DIMM slot (up to 4GB)
Expandable Storage
• 1x SATAIII SATA DOM Slot (available option 16GB, 32GB, 64GB and
128GB)
Expansion
• 1x Half Mini-PCIe socket (PCIe + USB) for WLAN option
• 1x Mini-PCIe socket ((USB + UART) for WWAN option)
• 1x External module for OBD SAE J1939 protocols/Battery module option
(UART + USB)
I/O Interfaces - Front
• F1~ F5 functions key
• Light sensor
• Internal mic-in
• 2x Built-in 2W speakers
• 3x LED indicators (Power mode, Storage and WWAN status)
I/O Interfaces - Lateral
Right side
• 1x Micro SD card socket
• 1x SIM card socket
• 1x USB 3.0 host type A connector
• 1x Mic-in, Line-out
Left side
• 1x Power button
• 1x System reset button
• Volume up/down or Brightness up/down
