VMC 1100 User Manual
Appendix A: I/O Address Function
IO ADDRESS: I/O port: 0ED1H
Bit0: WLAN2_DIS
0: Disable
1: Enable (*)
Bit1: GPS_PWR_EN
0: Disable
1: Enable (*)
Bit2: Modem_PWR_EN
0: ON (*)
1: OFF
Bit3: Modem_SEL
0: ON (*)
1: OFF
Bit4: COM2 RS485/RS422
0: COM2 RS485 (*)
1: COM2 RS422
Bit5: COM2 RS232 / RS485_RS422
0: COM2 RS232 (*)
1: COM2 RS485/RS422
IO ADDRESS: I/O port: 0EDCH
Bit 5-7: Type
000: VTC
001: VMC
010: nROK
Bit 0-4: Model
Bit 0-4: 00001
Bit 5-7: 001
